CONTROLS 42

5.43Center stand

100529-10

The vehicle is equipped with a center stand  in addition to a side stand.

5.44Passenger footrests

100530-10

The passenger footrests can be folded up and down.

Possible states

• Passenger footrests folded up – For operation without a passenger.

• Passenger footrests folded down – For operation with a passenger.
