MAINTENANCE WORK ON FRAME AND ENGINE 125
100589-11
– Position side cover at the fuel tank on the bottom and hold it at an angle.
– Attach the overflow hose of the fuel tank to the connector.
– Connect the plug-in connectors of the turn signal cables and swing the side cover up
toward the vehicle.
– Mount and tighten screws with the washers.
Guideline
Remaining chassis nuts M6 15 Nm
(11.1 lbf ft)
– Check the function of turn signal.
9.53Removing the headlight mask with the headlight
– Switch off all power consumers and the engine.
– Remove the front side cover. ( p. 124)
100590-10
– Unhook the headlight mask from the cockpit holder and remove it toward the front.
