MAINTENANCE WORK ON FRAME AND ENGINE 133
The light-dark boundary must lie exactly on the lower mark when the motorcycle is
ready to operate with the rider mounted along with any luggage and a passenger if
applicable.
» If the boundary between light and dark does not meet specifications:
– Adjust the headlight range. ( p. 133)
9.62Adjusting the headlight range
– Check the headlight setting. ( p. 132)
100598-10
– Turn adjusting screw to adjust the headlight range.
Guideline
For a motorcycle with rider, and with luggage and a passenger if applicable, the
light/dark boundary must be exactly on the lower mark (applied in: Checking
headlight adjustment).
Info
Turn clockwise to increase the light range, turn counterclockwise to reduce the
light range.
If you have a heavy payload, you will need to correct the headlight range.
9.63Activating/deactivating the ignition key
Info
The orange programming key must only be used for activating and deactivating!
If a black ignition key is lost or replaced, the black ignition keys must be activated/deactivated using the orange programming key.
This will also prevent the vehicle from being operated without authorization with the lost black ignition key.
You can activate or deactivate up to four black ignition keys. Only the black ignition keys trained during an activation procedure are
valid. All black ignition keys not trained in the activation procedure are invalid, but can be retrained in a further activation proce-
dure.
