MAINTENANCE WORK ON FRAME AND ENGINE 68
9.6Adjusting the compression damping of the fork
Info
The hydraulic compression damping determines the fork suspension behavior.
100533-10
– Remove protection covers .
– Turn adjusting screws clockwise until they stop.
Info
The adjusting screws are located at the bottom end of the fork legs.
Make the same adjustment on both fork legs.
– Turn back counterclockwise by the number of clicks corresponding to the fork type.
Guideline
(990 Adventure)
Compression damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
(990 Adventure R)
Compression damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
