BRAKES
L3560, L4060, L4760, L5060, L5460, L6060, WSM
5-S3
3. TIGHTENING TORQUES
Tightening torques of screws and nuts in the table below are especially specified.
(For general use screws and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.)
9Y1210824BRS0003US0
Item N·m kgf·m lbf·ft
Rear wheel mounting screw and nut 197 to 225 20.0 to 23.0 145 to 166
ROPS lower frame mounting screw 167 to 196 17.0 to 20.0 123 to 144
Cabin mounting bolt and nut 124 to 147 12.6 to 15.0 91.5 to 108
Cabin mount bracket mounting screw (7T) 124 to 147 12.6 to 15.0 91.5 to 108
Cabin mount bracket mounting screw (9T) 167 to 196 17.0 to 20.0 123 to 144
Rear axle case mounting screw (M10) 48 to 55 4.9 to 5.7 36 to 41
Rear axle case mounting nut (M10, 9T) 61 to 70 6.2 to 7.2 45 to 52
Rear axle case mounting screw (M12) 78 to 90 7.9 to 9.2 58 to 66
Brake case mounting screw and nut 78 to 90 7.9 to 9.2 58 to 66
Floor seat mounting bolt and nut 200 to 220 20 to 23 150 to 160
Fulcrum screw (Manual tranmission and GST) 40 to 44 4.0 to 4.5 29 to 32
Fulcrum screw (HST) 63 to 72 6.4 to 7.4 47 to 53
Brake cam lever mounting nut 63 to 72 6.4 to 7.4 47 to 53
