Kubota WSM L5460 User Manual

FRONT AXLE
L3560, L4060, L4760, L5060, L5460, L6060, WSM
6-S3
9Y1210824FAS0002US0
Front Axle Case Boss (Front) to Bracket
Bushing
• Front Axle Case Boss (Front)
• Bushing
Clearance
O.D.
I.D.
0.120 to 0.275 mm
0.00473 to 0.0108 in.
49.950 to 49.975 mm
1.9666 to 1.9675 in.
50.095 to 50.225 mm
1.9723 to 1.9773 in.
0.50 mm
0.020 in.
–
–
Front Axle Case Boss (Rear) to Bracket
Bushing (L3560 and L4060)
• Front Axle Case Boss (Rear)
• Bushing
Clearance
O.D.
I.D.
0.100 to 0.292 mm
0.00394 to 0.0114 in.
69.970 to 70.000 mm
2.7548 to 2.7559 in
70.100 to 70.262 mm
2.7599 to 2.7662 in.
1.0 mm
0.039 in.
–
–
Front Axle Case Boss (Rear) to Bracket
Bushing (L4760, L5060, L5460 and L6060)
• Front Axle Case Boss (Rear)
• Bushing
Clearance
O.D.
I.D.
0.025 to 0.195 mm
0.00099 to 0.00767 in.
80.000 to 80.035 mm
3.1496 to 3.1509 in.
80.060 to 80.195 mm
3.1520 to 3.1572 in.
0.50 mm
0.020 in.
–
–
Bevel Gear Case Boss to Front Axle
Support Bushing
(L4760, L5060, L5460 and L6060)
• Bevel Gear Case Boss
• Front Axle Support Bushing
Clearance
O.D.
I.D.
0.080 to 0.248 mm
0.0032 to 0.00976 in.
54.970 to 55.000 mm
2.1642 to 2.1653 in.
55.080 to 55.218 mm
2.1685 to 2.1739 in.
1.0 mm
0.039 in.
–
–
Item Factory Specification Allowable Limit
KiSC issued 03, 2016 A
