KYMCO MXU 450i Service Manual

6-1
6
SECTION 6 - DRIVE SYSTEM
TABLE OF
CONTENTS
Drive System........................................................... 6-2
Front Drive Actuator ................................................ 6-2
Front Differential...................................................... 6-3
Drive Axles............................................................ 6-14
Rear Gear Case .................................................... 6-18
Hub........................................................................ 6-19
Hydraulic Brake Caliper......................................... 6-20
Troubleshooting Drive System...............................6-22
Troubleshooting Brake System.............................. 6-22
