Frame Rate 30fps (pictures/sec)
Image Sensor 1/12" CMOS
White Balance Automatic
Exposure Automatic
Light Source 4 adjustable LEDs
Power Supply 5V
Ambient temperature 0 to +65
o
C
Data Cable Length Approx. 2000mm
Probe & Camera Length 1030mm
Probe Cable Length 830mm
Min. Bending Radius 50mm
Lens Diameter 7.0mm
Probe Tube Diameter 6.0mm
Viewable Angle 60
o
Lens Focal Length More than 50mm
Net Weight Approx. 270g
4.5.4 Connections & Operations
1. Insert the USB cable into the USB hub on the diagnostic workbench.
2. Bend the neck of the exible tube as desired and extend the camera with adjustable LED lights to some
unseen or unreachable parts of engine, hydraulic system, nozzles etc.
3. After connections are properly made, tap or click "X-431 Station" to launch it. Switch to the "Toolbox"
module and tap or click "Videoscope" to run it, then the screen will display the scene captured from the
videoscope camera.
4. Adjust it until the lens stops in the desired place, then use the dial for LED light brightness to adjust the
brightness.
5. Press the Snapshot button on the videoscope to take a photo.
To record a video, switch from Camera mode to Video mode and tap the Record button on the screen to
start recording.
Images are captured in .jpg format and videos are recorded in .avi or .mp4 format. All photographings and
videos are saved in DCIM folder where users can browse and replay it.
4.6 Wallet
Wallet App is a point (token) management application tailored for healthy vehicle maintenance. Those who
share the Wallet App with car owner will be rewarded 1 point (token) when this car owner successfully
registered. Later, the points will bring many unexpected benets to you and the recommender. For example,
use the points to redeem merchandise or enjoy discount.
4.6.1 Registering Wallet
Refer to Chapter 2.3 Register & Download Diagnostic Software for details.
