Config...\Interfaces... - General GPS1200 133
20.2.3 Configuration of a Reference Real-Time Interface
Access Select Main Menu: Config...\Interfaces.... Highlight Real-Time. EDIT (F3).
CONFIGURE
Real-Time Mode
The available fields and keys on this screen depend on the selected settings.
)
Two real-time devices can be attached to two different ports, for example a radio and
a digital cellular phone. On the reference, the two devices can operate simultane-
ously. Press SHIFT RT-2 (F2) to configure a second real-time interface.
Description of fields
CONT (F1)
To accept changes and return to the
screen from where this screen was
accessed.
REF (F2)
To configure additional settings rele-
vant to reference, e.g. time slicing.
RATES (F3)
To configure the data rates for the
selected real-time data format.
SRCH (F4)
Available on RX1250 with <Port:
Bluetooth x> and a Bluetooth device
being selected. To search for all
available Bluetooth devices. If more
than one Bluetooth device is found a
list of available devices is provided.
DEVCE (F5)
Available unless <Port: NETx>. To
create, select, edit or delete a device.
SHIFT RT-2 (F2)
To accept the settings and configure
a second reference real-time inter-
face.
SHIFT SBAS (F5)
To configure the Space-Based
Augmentation System to be used.
Field Option Description
<R-Time
Mode:>
None, Refer-
ence or Rover
<R-Time Data: Reference> activates a refer-
ence real-time interface.
<R-Time
Data:>
Leica The proprietary Leica real-time GPS data
format. This is recommended when working
exclusively with Leica receivers.
CMR
CMR+
CMR and CMR+ are compacted formats used to
broadcast data for third party receivers.
