Config...\Interfaces... - Controlling
Devices
GPS1200 163
22.3 Radios
Description For radios the channels on which the radio broadcasts can be changed. Changing
channels changes the frequency at which the radio operates.
Access Refer to "22.1 Accessing Config...\Interfaces... - Controlling Devices" to access
CONFIGURE Radio Channel.
)
Channel changing may contravene radio broadcasting regulations in certain coun-
tries. Before operating with radios, check the regulations in force in the working area.
)
If channel changing is to be used, when configuring the reference real-time interface,
set <Ref Stn ID:> in CONFIGURE Additional Reference Options, General page
to a different ID for each reference site. By doing so, the rover can recognise if the
incoming real-time data after channel changing is being received from a different
reference station or if the original reference station is using a new frequency. In the
first case, the ambiguities are recomputed.
CONFIGURE
Radio Channel
Description of fields
CONT (F1)
To accept the changes and to
continue with the subsequent
screen.
SCAN (F5)
To find out information such as the
station ID, latency and the data
format of incoming signals from
reference stations.
Field Option Description
<Radio
Type:>
Output The type of radio highlighted when
CONFIGURE Radio Channel was accessed.
<Channel:> User input The radio channel. The minimum and maximum
allowed input values for a radio depend on the
number of channels supported by the radio and
the spacing between the channels.
<Actual
Freq:>
Output Available for <Radio Type: Satelline 3AS>.
Displays the actual frequency of the radio.
