92 GPS1200 Convert...\Export Data from Job
14.3 Exporting DXF Data
General Data can be exported to a DXF file in the \DATA directory of the CompactFlash card
or the internal memory, if fitted.
Access Select Main Menu: Convert...\Export Data from Job\DXF Export.
DXF Export
Export DXF from
Job
Description of fields
CONT (F1)
To export the data.
CONF (F2)
To define elements to be exported,
how they will be exported and if
labels will be created.
Field Option Description
<Job:> Choicelist If points from a job on the internal memory are to
be exported, open this choicelist. When in this
choicelist press CFCRD (F6) or INTL (F6) to
select a job from a different memory device.
<Coord
System:>
Output The coordinate system currently attached to the
selected <Job:>.
<File Name:> User input Available for <Export To: CF Card> and
<Export To: Internal Memory>. The name of
the file to which the data should be exported.
The name is automatically suggested based on
the job name to be exported and extension dxf.
<Progress:> Output Progress bar. Displays progress of the export.
To Next Page
