Config...\Interfaces... - General GPS1200 139
Description of fields
Field Option Description
<R-Time
Mode:>
None, Refer-
ence or Rover
<R-Time Data: Rover> activates a rover real-
time interface.
<R-Time
Data:>
Leica
CMR/CMR+
RTCM v3
RTCM 1,2 v2
RTCM 9,2 v2
RTCM 18,19 v2
RTCM 20,21 v2
Refer to "20.2.3 Configuration of a Reference
Real-Time Interface" for information about these
real-time data formats.
The availability of the following options depend
on the selection made for <SBAS Tracking:> in
CONFIGURE SBAS Tracking Mode.
WAAS/EGNOS/
MSAS, EGNOS,
WAAS, MSAS,
EGNOS (Test) or
WAAS (Test)
Wide Area Augmentation System
European Geostationary Navigation Overlay
Service
MTSAT Satellite-based Augmentation System
where MTSAT stands for Multi-functional Trans-
port SATellite
<Port:> Bluetooth x Available for RX1250. The Bluetooth port which
will be used for the interface functionality.
Clip-on Available for RX1250. The clip-on-contacts. It is
used for RX1250 with GHT56 when a device is
attached to the GHT56.
NETx Available for an activated Internet interface. If
these ports are not assigned to a specific inter-
face, then these ports are additional remote
ports.
Port x The physical port P1, P2 or P3 on the instrument
to which the device is attached.
<ID
Address:>
Output Available on RX1250 with <Port: Bluetooth x>
and a Bluetooth device being selected.
The ID address of the SmartAntenna to be used.
<Ref
Sensor:>
Choicelist The receiver type used at the reference. If the
real-time data format does not contain the infor-
mation of the receiver type certain corrections
based on the information of the receiver type are
applied in order to provide correct results. The
real-time data formats Leica, CMR and CMR+
contain this information. This is mainly important
when a System300 receiver is used as refer-
ence.
