Information SET-01 83
DIGITAL plus
The following transformers are recommended for the LV101:
• Digital plus TR100 (order-no. 26000).(220 volts)
• Digitrax PS515 Power supply (110 volts)
• Atlas Generator (110 volts)
• MRC AH800 Power supply (110 volts)
• Lionel Trainmaster PH1 (note this transformer can power 2
LV101s) (110 volts)
If you wish to use a different transformer, please note that it should
be a model railroad transformer with a 'UL,'GS' or 'CE' symbol.
17.5 Power Station LV101
In SET-01 the power station LV101 provides DCC power to the
tracks. Features include user selectable DCC track voltage, a fault
detection LED, and a RJ-45 plug-in connector for connecting the
LH200 command station and XpressNet.
The DIGITAL plus Power Station LV101 provides clean and safe
DCC power to the track. New circuitry has been developed to reduce
noise, which provides exceptionally clean power to operate your
DCC equipped trains. Safety features include:
• Short/overload detection that turns off the power to the track
whenever a short or overload condition is detected. This
protects both your trains and the LV101 electronics.
• Opto-isolation to safely isolate your control bus wiring from your
track wiring. This eliminates any possibility for hidden ground
loops through your power station.
• Fail Safe runaway protection is provided by requiring a 7 volt
signal on the DCC Control Bus (the C and D wires). This
prevents the LV101 from accidentally sending out power to the
track when the command station stops transmitting packets.
The LV101 provides a fault detection LED located on the front of the
unit. When the power station is in use, the LED on the front is lit. In
case of an overload of the power station, the LED will flash. In
addition, the LED will also flash if no information is being transmitted
over the Control Bus (connections C and D), The LH200 command
station is disconnected, the LH200 command station is off or one of
the wires in not connected.
The LV101 Power Station was designed to meet all NMRA
Standards and RPs including the new the NMRA Control Bus draft
RP.
