Lenze ECSxK001 series User Manual

Monitoring functions
Configuring monitoring functions
Monitoring times for process data input objects
10

202
EDBCSXA064 EN 3.2
10.3 Configuring monitoring functions
10.3.1 Monitoring times for process data input objects
Fault message Monitoring function System variable
Possible response
TRIP Messag
e
Warnin
g
Off
x062 CE1 Communication error at the
process data input object
CAN1_IN
CAN_bCe1CommErrCanIn1_b ü ü ·
x063 CE2 Communication error at the
process data input object
CAN2_IN
CAN_bCe2CommErrCanIn2_b ü ü ·
x064 CE3 Communication error at the
process data input object
CAN3_IN
CAN_bCe3CommErrCanIn3_b ü ü ·
x065 CE4 BUS−OFF state of the CAN bus
at interface X4 (CAN)
CAN_bCe4BusOffState_b ü ü ·
x122 CE11 Communication error at the
process data input object
CANaux1_IN
CANaux_bCe1CommErrCanIn1_
b
ü ü ·
x123 CE12 Communication error at the
process data input object
CANaux2_IN
CANaux_bCe2CommErrCanIn2_
b
ü ü ·
x124 CE13 Communication error at the
process data input object
CANaux3_IN
CANaux_bCe3CommErrCanIn3_
b
ü ü ·
x125 CE14 BUS−OFF state of the CAN bus
at interface X14 (CAN−AUX)
CANaux_bCe4BusOffState_b ü ü ·
· Default setting
üSetting possible
Each process data input object can monitor whether a telegram has been received within
a specified time. As soon as a telegram arrives, the corresponding monitoring time
(C0357/C02457) is restarted ("retriggerable monoflop" function).
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0357 Monitoring time for CAN1...3_IN
(CAN bus interface X4)
 202
1 CE monit time 3000 1 {1 ms} 65000 CE1 monitoring time
2 CE monit time 3000 CE2 monitoring time
3 CE monit time 3000 CE3 monitoring time
