Lenze ECSxK001 series User Manual

System modules
MCTRL_MotorControl (node number 131)
Setting maximum speed
13

357
EDBCSXA064 EN 3.2
13.20.5 Setting maximum speed
The maximum speed (n
max
) which is used as a reference variable for the absolute and
relative setpoint selection with regard to the acceleration and deceleration times as well
as to the upper and lower speed limit, is set via C0011.
ƒ n
max
= 100 % º (INT) 16384
 Note!
MCTRL_nNmaxC11 displays the maximum speed set via C0011.
ƒ By means of this system variable, you are able to program your own speed
scalings.
ƒ Example: C0011 = 3000 rpm ð MCTRL_nNmaxC11 = 3000
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0011 Nmax 3000
Maximum speed
 357
500 {1 rpm} 16000 Reference value for the absolute
and relative setpoint selection
for the acceleration and
deceleration times.
For parameter setting via
interface: greater changes in one
step should only be made when
the controller is inhibited (CINH)!
