Lenze ECSxK001 series User Manual

System modules
CANaux_Management (node number 111)
Inputs_CANaux_Management
13

300
EDBCSXA064 EN 3.2
13.11.1 Inputs_CANaux_Management
System variables
Variable Data
type
Signal
type
Address Display
code
Display
format
Comments
CANaux_bCe11Comm−E
rrCanIn1_b
BOOL
binary
%IX111.0.0
˘ ˘
CANaux1_IN
communication error
CANaux_bCe12Comm−E
rrCanIn2_b
%IX111.0.1 CANaux2_IN
communication error
CANaux_bCe13Comm−E
rrCanIn3_b
%IX111.0.2 CANaux3_IN
communication error
CANaux_bCe14BusOffSt
ate_b
%IX111.0.3 CAN bus "Off State"
detected (CAN bus
interface X14)
CANaux_byNode−Addres
s
Byte ˘
%IB111.2
C2450 ˘
Node address
(CAN bus interface X14)
CANaux_byState %IB111.3
C2459 ˘
CAN bus status
(CAN bus interface X14)
13.11.2 Outputs_CANaux_Management
System variables
Variable Data
type
Signal
type
Address Display
code
Display
format
Comments
CANaux_bResetNode_b
BOOL
binary
%QX111.0.0
˘ ˘
Carry out reset node
(CAN bus interface X14)
CANaux_bTxCan2Synchr
onized_b
%QX111.0.1 Transmit CANaux2_OUT
with sync telegram.
CANaux_bTxCan3Synchr
onized_b
%QX111.0.2 Transmit CANaux3_OUT
with sync telegram.
