Lenze ECSxK001 series User Manual

Monitoring functions
Configuring monitoring functions
Motor temperature sensor monitoring (Sd6)
10

223
EDBCSXA064 EN 3.2
10.3.15 Motor temperature sensor monitoring (Sd6)
Fault message Monitoring function System variable
Possible response
TRIP Messag
e
Warnin
g
Off
086 Sd6 Motor temperature sensor
fault
MCTRL_bSensorFault_b ü ü ·
· Default setting
üSetting possible
This monitoring function checks whether the motor temperature sensor supplies values
within the measuring range of −50 ... +250 °C. If the values are outside this measuring
range, monitoring is activated.
The response is set via C0594.
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0594 MONIT SD6 3
Fault response − monitoring
KTY sensor for the motor
temperature.
"SensorFault" (Sd6)
 223
0 TRIP
2 Warning
3 Off
