Lenze ECSxK001 series User Manual

System modules
DCTRL_DriveControl (node number 121)
Setting TRIP (TRIP−SET)
13

326
EDBCSXA064 EN 3.2
13.15.6 Setting TRIP (TRIP−SET)
This function sets "TRIP" in the drive and reports "external error" (error message "EEr").
ƒ The function can be controlled via the following inputs (OR’d):
– Control word DCTRL_wAIF1Ctrl ( 259)
– Control word DCTRL_wCAN1Ctrl ( 283)
– Control word C0135, bit 10
– Variable DCTRL_bTripSet_b (TRUE = set TRIP)
ƒ C0136/1 indicates the control word C0135.
ƒ The reaction to TRIP can be set via C0581:
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0581 MONIT EEr 0
Fault response − external fault
monitoring "ExternalFault" (EEr)
 326
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
13.15.7 Resetting TRIP (TRIP−RESET)
This function resets an upcoming TRIP if the cause of malfunction is eliminated. If the cause
of malfunction is still active, no response will be effected.
ƒ The function can be controlled via the following inputs (OR’d):
– Control word DCTRL_wAIF1Ctrl ( 259)
– Control word DCTRL_wCAN1Ctrl ( 283)
– Control word C0135, bit 11
– Variable DCTRL_bTripReset_b
– Code C0043
ƒ C0136/1 indicates the control word C0135.
 Note!
The function is only carried out by a FALSE−TRUE edge of the signal resulting
from the OR operation.
If one input is assigned to TRUE, a FALSE−TRUE edge cannot occur.
