Appendix
Table of attributes
14
431
EDBCSXA064 EN 3.2
14.6 Table of attributes
If you want to establish separate programs, you need the information from the table of
attributes. It contains all information for the communication to the ECSxA... axis module
via parameters.
How to read the table of attributes:
Column Meaning Entry
CoDe Name of the Lenze code Cxxxx
Index
dec
Index used to address a
parameter
A subindex of an array variable is
the same as a Lenze subcode
number
24575 − Lenze codes
Only needed for control via INTERBUS−S,
PROFIBUS−DP, or system bus (CAN).
hex 5FFFh − Lenze code
Data DS Data structure
E Single variable (one parameter element only)
O Array variable (several parameter elements)
DA Number of the array elements
(subcodes)
DT Data type
B8 1 byte bit coded
B16 2 bytes bit coded
B32 4 bytes bit coded
FIX32 32 bit value with sign; decimal with four
decimal positions
I32 4 byte with sign
U16 2 byte without sign
U32 4 byte without sign
VS ASCII string
Format LECOM format
(see also the Operating
Instructions for the 2102 fieldbus
module)
VD ASCII decimal format
VH ASCII hexadecimal format
VS String format
VO Octett string format for data blocks
DL Data length in bytes
Decimal
position
Number of decimal positions
Access LCM−R/W Access authorisation for LECOM
Ra Reading is always permitted
Wa Writing is always permitted
W Writing is bound to a condition
Condition Writing condition
CINH Writing is only permitted when the controller
is inhibited (CINH)
PLC run Writing is only permitted when the program
is running.
