System modules
CANaux1_IO (node number 34)
Outputs_CANaux1
13

307
EDBCSXA064 EN 3.2
13.12.2 Outputs_CANaux1
System variables
Variable Data
type
Signal
type
Address Display
code
Display
format
Comments
CANaux1_nOutW0_a integer analog %QW34.0 ˘ ˘
CANaux1_bFDO0_b
BOOL binary
%QX34.0.0
˘ ˘
... ...
CANaux1_bFDO15_b %QX34.0.15
CANaux1_nOutW1_a integer analog %QW34.1 C2493/1 dec [%]
CANaux1_bFDO16_b
BOOL binary
%QX34.1.0
˘ ˘
... ...
CANaux1_bFDO31_b %QX34.1.15
CANaux1_nOutW2_a integer analog %QW34.2 C2493/2 dec [%]
CANaux1_bFDO32_b
BOOL binary
%QX34.2.0
˘ ˘
... ...
CANaux1_bFDO47_b %QX34.2.15
CANaux1_nOutW3_a integer analog %QW34.3 C2493/3 dec [%]
CANaux1_bFDO48_b
BOOL binary
%QX34.3.0
˘ ˘
... ...
CANaux1_bFDO63_b %QX34.3.15
CANaux1_dnOutD1_p double
integer
position %QD34.1 ˘ ˘
