Diagnostic information 2-1
5025-2xx, 4xx
2. Diagnostic information
Start
Begin here to locate the service error code, user status message, user error message, symptom table, service
checks, and diagnostic aids in this chapter to determine the corrective action necessary to repair a
malfunctioning printer. They will lead you to solutions or service checks, including use of various tests.
• Does the POR stop? Check the “POR (Power-On Reset) sequence” on page 2-2.
• Do you have a symptom, rather than an error message? Locate your symptom and take the appropriate
action:
– “Printer symptom table” on page 2-3
– “Print quality symptom table” on page 2-4
• Do you have an error message or persistent user message, check the following:
– “Service error messages” on page 2-13
– “User status and customer attendance messages” on page 2-5
– “Paper Jam messages” on page 2-11
– “Paper jams” on page 3-31
– “Service checks” on page 2-22 for individual error messages
• Additional information can be found at the following locations:
– “User operator panel and Administration menus” on page 2-58
– “Theory of operation” on page 3-37
CAUTION
Unplug power cord from the electrical outlet before you connect or disconnect any cable or
electronic board or assembly for personal safety and to prevent damage to the printer.
Disconnect any connections between the printer and PCs/peripherals.
