Starting the engine for driving / switching it off
4.2 Switch off the engine
Operating manual 3 302 690 en 4 - 19
GMK4100L-1
23.11.2017
4.2.2 Using the emergency stop switches
Emergency stop switch
Three emergency stop switches are provided
for emergency use:
• Press an emergency stop switch (1), (2)
or (3). The switch latches.
The engine shuts down.
H
If an air intake inhibitor is present, this is then triggered.
H
Do not operate the emergency stop switch to switch the engine off in
normal operation. Only operate the emergency stop switch in an
emergency situation.
Resetting the
emergency stop
switch
You can restart the engine only after you have reset the emergency stop
switch.
• Switch off the ignition.
• Turn the actuated emergency stop switch until it disengages again.
If air intake inhibitors are fitted, they must be released;
à Releasing the air
intake inhibitor
, p. 4 - 20.
1 On the carrier
2 On the hand-held control unit
3 In the crane cab
