Crane operation
11.7 Working range limiter
Operating manual 3 302 690 en 11 - 145
GMK4100L-1
23.11.2017
– For slewing angles
• Set the respective limit value and confirm
with button (3) or (4). The value is adopted.
– The symbol (1) for the slewing angle A –
symbol is red,
– The symbol (2) for the slewing angle B –
symbol is red.
Switch monitoring on;
à p. 11 - 146
– For the hoist rope travel
For hoist rope travel limitation the values (1)
and (2) cannot be entered manually.
