2016 OWNERS MANUAL / 0107
This screen displays any faults that have occurred for the Outputs,
Inputs and/or CAN Communication.
Faults are color coded as follows:
• Red (Short Circuit or Out of Range)
• Orange (Open Circuit)
• Yellow (Over-Current)
• Green (No Faults / Active / In Range)
To reset existing faults, touch.
To display the alternate PDM Diagnostics screen, touch
/ .
GPS Settings
NOTE: This option will only appear if a map card is installed.
Waypoint Manager
Waypoints allow you to mark specific locations by latitude and lon-
gitude. Once the waypoints are established, the Waypoint Manager
allows you to associate an icon with them for identification. You can
delete a single waypoint by using the DELETE key or all of them at
once with DELETE ALL. Pressing the GO TO … key displays the GPS
screen containing the currently highlighted waypoint.
