2016 OWNERS MANUAL / 0109
GPS Status
This option shows the location of discoverable satellites. Touch
DONE when finished.
Depth / Position Setup
This feature allows you to define the amount of detail to display
for longitude and latitude information on the GPS map and depth
display. Touch DONE when finished.
TROUBLESHOOTING
Display appears not to work or doesn’t come ON.
1. Display could be in sleep mode. Touch a key on the
keypad to activate the display.
2. Check for loose connections at battery and display unit.
3. Check for reversed polarity on the power connections.
4. Verify battery has a minimum voltage of 6 volts.
Display resets or goes OFF when starting engine.
1. Check display supply wires are connected properly to battery.
2. Verify battery is charged properly.
3. Check battery for efficient starter current.
Display has no back light.
Contact your MasterCraft service center.
Display has no keypad back light.
Contact your MasterCraft service center.
