2016 OWNERS MANUAL / 065
FEATURES
01. Anchor storage
02. Ladder (where equipped)
03. Bow cleat
04. Horn
05. Ballast tank (beneath floorboard)
06. Circuit breaker panel (on kick panel beneath
instrument panel)
07. Navigation light
08. Instrument panel (details in Video Display
Gauge section)
09. Adjustable mirror
10. Steering wheel
11. Shift/throttle control
12. Heated seat (where equipped)
13. Fire suppression unit manual override
14. Midship cleat
15. Cooler (under seat)
16. Fuel tank filler
17. Engine compartment
18. Automatic fire extinguisher
19. Engine compartment exhaust (two, on top of
port and starboard near transom)
20. Stern cleat
21. Stern light receptacle (if equipped with tower,
light will be in center aft of tower)
22. Freshwater flush port (where equipped)
23. Underwater lights (two, where equipped,
under swim platform)
24. Transom drain plug (center beneath
swim platform)
25. Removable ski pylon (where equipped)
26. Bow cleat
27. Bow filler cushion (where equipped)
28. Amp (where equipped)
29. Navigation light
30. Glove box
31. Stereo remote (on dash)
32. Center drain plug (access plate under
carpet mat)
33. Observer seat
34. Subwoofer
35. Batteries (under seat)
36. Washdown connection
37. Midship cleat
38. Battery ON-OFF switch (under seat)
39. Reversible seating
40. Fuel tank filler
41. Stern cleat
42. Freshwater tank fill
43. Surf tabs (each side, under swim
platform, where equipped)
44. Wake adjustment plate (under swim
platform, where equipped)
45. Swim platform
46. Transom rail with tow eye
SPECIFICATIONS
Length of Boat 24’6”
Width Amidship 102”
Boat Weight 5,350 lbs.
Length of Boat w/Platform 26’ 9”
Towing Length 30’ 10”
Towing Width 102”
Fuel Capacity 79 gallons
Maximum Capacity 15 people
or 2,142 lbs.
Bow: 5 people or 700 lbs.
Weight must be evenly distributed.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, port and starboard sun pads.
X46
