MEETING

If you are meeting another vessel head-on, and you are close

enough to run the risk of collision, neither of you has the right-

of-way. Both of you should alter course to avoid an accident. You

should keep the other vessel on your port (left) side. (This rule

doesn’t apply if both of you can clear each other by continuing your

set course and speed.)

)

2 short blasts (1 sec. each)

1 short blast (1 sec.) 1 short blast (1 sec.
