2016 OWNERS MANUAL / 063
FEATURES
01. Anchor storage
02. Bow cleat (where equipped))
03. Horn
04. Ballast tank below floor board
05. Bilge thru-hull outlet
06. Ballast thru-hull vent
07. Navigation light
08. Circuit breaker panel (on kick panel beneath
instrument panel)
09. Instrument panel (details in Video Display
Gauge section)
10. Stereo remote (on dash)
11. Steering wheel
12. Shift/throttle control
13. Heated seat (where equipped)
14. Fire suppression unit manual override
15. Subwoofer (where equipped)
16. Cooler (under seat)
17. Garbage can
18. Midship cleat
19. Fuel tank filler
20. Bilge thru-hull vent
21. Reversible seating
22. Engine compartment
23. Stern cleat
24. Automatic fire extinguisher
25. Molded-in boarding platform
26. Stern light receptacle (if equipped with tower,
the light will be in center aft of tower)
27. Transom stereo remote (where equipped)
28. Underwater lights (two, where equipped)
29. Wake adjustment plate (where equipped)
30. Bow cleat (where equipped)
31. Bow filler cushion (where equipped)
32. Adjustable mirror
33. Navigation light
34. iPod interface (where equipped)
35. Glove box
36. Batteries (under seat)
37. Amp (where equipped)
38. Hand-held fire extinguisher (beneath
observer seat)
39. Heated observer seat (where equipped)
40. Center drain plug (under inspection plate)
41. Midship cleat
42. Fuel tank filler
43. Batteries ON-OFF switch (under seat)
44. Ski pylon
45. Ballast thru-hull vent
46. Stern cleat
47. Freshwater tank (where equipped)
48. Shower wand & switch (where equipped,
inside compartment)
49. Engine exhaust (each side)
50. Transom rail with tow eye
51. Transom drain plug
52. Teak platform (or fiberglass, where equipped)
SPECIFICATIONS
Length of Boat 23”4’
Width Amidship 102”
Boat Weight 4,700 lbs.
Length of Boat w/Platform 25’7
Towing Length 28’ 6”
Towing Width 102”
Fuel Capacity 60 gallons
Maximum Capacity 16 people
or 2,219 lbs.
Bow: 5 people or 700 lbs.
Weight must be evenly distributed.
X30
