2016 OWNERS MANUAL / 0137
Depth and Position Set-up
Use the Depth and Position Set-up on the 4.5” touch screen and
the results can be immediately seen on the map displayed on the 7”
touch screen.
For example, modify the Depth Contour or the Safety Contour, the
contours are immediately shown on the 7” touch screen. The Depth
and Position Setup screen can be closed by touching [X].
GPS Status
The GPS Status screen on the 4.5” touch screen is identical to the
GPS Status screen on the 7” touch screen. It shows the status of
detectable satellites and their locations.
Track Menu
Touch menu to:
• Find the current position on the map;
• Create waypoints;
• Clear track;
• Save track.
