MasterCraft X23 User Manual

2016 OWNERS MANUAL / 061
FEATURES
01. Anchor storage
02. Bow cleat
03. Horn
04. Bilge thru-hull outlet
05. Ballast thru-hull vent
06. Ballast tank (located beneath floorboard)
07. Lifting bow back
08. GPS puck
09. Navigation light
10. Adjustable mirror
11. Instrument panel
(details in Video Display Gauge section)
12. Steering wheel
13. Midship cleat
14. Shift-throttle control
15. Heated seat (where equipped)
16. Fire suppression unit manual override
17. Subwoofer (where equipped)
18. Cooler (under gas-assisted seat lift)
19. Navigation light
20. Fuel tank fill
21. Stern cleat
22. Automatic fire extinguisher
(inside engine compartment)
23. Engine compartment
24. Sea strainer
25. Ballast thru-hull vent
26. Bilge pump
27. Transom lounge seating (as pictured) or
standard flip-up transom seating
(neither seat for use while underway)
28. Engine exhaust (under swim platform)
29. Underwater lights
(two, where equipped, under swim platform)
30. GEN2 wake shaping device
(under swim platform, where equipped)
31. Bow ladder lid
32. Bow cleat
33. Bow filler cushion (where equipped)
34. Flip down armrest
35. Glovebox
36. Navigation light
37. Batteries ON-OFF switch (walk-thru side panel)
38. Circuit breaker panel (walk-thru side panel)
39. Stereo remote (on dash)
40. Amp (where equipped, under observer seat)
41. Mid-ship cleat
42. Hand-held fire extinguisher
(beneath observer seat)
43. Observer seat (heated, where equipped)
44. Center drain plug (under inspection plate)
45. Heater vent (where equipped)
46. Batteries (under seat)
47. Reversible seating (where equipped)
48. Removable ski pylon
49. Fuel tank fill
50. Stern cleat
51. Bilge thru-hull air vent
52. Ballast thru-hull air vent
53. Transom stereo remote (where equipped)
54. Wake adjustment plate (under swim platform)
55. Under-platform ladder (where equipped)
SPECIFICATIONS
Length of Boat 22’ 9”
Width Amidship 102”
Boat Weight 5,500 lbs.
Length of Boat w/Platform 24’ 8”
Towing Length 28’ 2”
Towing Width 102”
Fuel Capacity 57 gallons
Maximum Capacity 15 people
or 2,126 lbs.
Bow: 4 people or 600 lbs.
Weight must be evenly distributed.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, port and starboard sun pads.
X23
