Fault Code Pop-ups
A fault condition will trigger a pop-up dialog box on the screen
describing the nature of the fault.
How to Hide/Show Faults
To hide the fault code pop-up being displayed on the screen, press
the soft key next to the “Hide” icon. The pop-up will disappear.
However, the “Warning” or “Stop” icon will remain on the screen to
indicate there is still a fault. Pressing “Hide” does not clear the fault;
it only hides the pop-up message.
When a fault code has been hidden, a “Show” icon will remain in the
bottom right corner. When this soft key is pressed, the fault code
will again be displayed.
Scrolling Through Multiple Messages
The title bar of the fault code pup-up may indicate multiple
messages, as in “Diagnostic Message 1 of 3.” Press to scroll through
the different messages.
USER SETTINGS
User Settings provide options to specify viewing preferences.
Pressing [PREV] or [NEXT] navigates through the options, and [UP]
and [DOWN] scrolls through the selections for each option.
User Settings-Soft Key Commands
Function and Description
PREVIOUS —Provides the ability to navigate through the set-
tings displayed on the screen. Selects the previous setting.
NEXT—Provides the ability to navigate through the set-
tings displayed on the screen. Selects the next setting.
UP/INCREASE—Allows changing the values within the
settings.
DOWN/DECREASE—Decreased the value in the setting.
ENTER—Creates a new user profile from the current
cruise settings.
To Next Page
