Troubleshooting
• If the switch(es) is/are unresponsive, check the main circuit
break panel to determine if the circuit has tripped. Reset the
circuit and try the switch again.
• If the circuit continues to trip, present the boat to an authorized
MasterCraft dealer for repair.
• If the boat does not respond as noted in the above instructions,
turn OFF the switch and do not use the attitude adjustment
function until the system has been checked by authorized
MasterCraft dealer because malfunction can result in loss of
control of the boat.
GEN2 SURF SYSTEM
Models
All X-Series and XStar, as an option.
Purpose
The GEN2 Wake Shaping Devices (WSDs) can be used in synch
with presets or manually adjusted to help build and shape the
surf wake to assist the rider in gaining a bigger push and a longer
optimum ride for surfing. The center attitude adjustment plate (see
instructions immediately above) can aid in this as well.
Location
The WSDs are installed on the port and starboard sides of the
boat’s stern. The switch is located on the armrest or it can be
controlled through the Video Display Gauge.
Operation
In the presets, SURF RIGHT will deploy the port WSD, and SURF
LEFT will deploy the starboard WSD. Surf tabs can also be used as
trim tabs to help level the boat that has an unbalanced load on port
or starboard or when a strong wind is present. Press the right trim
button to make the boat rotate to the right (starboard) and press
the left trim button to make the boat rotate left (port). To raise all
devices, press and hold the UP button until the center attitude is at
zero percent (0%). Release and press the UP button again to raise
the GEN2 WSDs to zero percent (0%). This information will also
appear in the Video Display Gauge, as equipped, and operates in the
same manner.
