2016 OWNERS MANUAL / 0261
Purpose
Lights improve aft deck, swim platform and body of water visibility
during low-light situations. Speakers provide enhanced enjoyment
of entertainment. Board racks allow for a safe and secure fashion of
carrying wakeboards and/or skis, and keeping them from underfoot
on the deck.
Location
All of these options are found on the tower.
Operation
Lights: The lights will be either can lights or LED lights. Either work
from a two-position, ON-OFF switch on the dash or driver’s armrest,
depending on model. Speaker ring lights and dimmer are an addi-
tional option, operated from a panel switch.
X-Series Speaker Lights: The speaker light switch panel is located
on or around the armrest on the X-Series boats. The switch turns
on the speaker lights in the cockpit and on the tower. The dimmer
switch located next to it will dim the lights they will remain in the
position that you left them in.
The XStar speaker light switch is located in the 4.3 touch under
lights. The switch will turn on the cockpit lights and the tower
speaker lights. In this boat you can’t adjust the dimming because it
is done in the digital switching.
Speakers: The speakers operate through the audio system. See
the Video Display Gauge information for your model in this Owner’s
Manual for instructions on how the volume is controlled.
Board Racks: When board racks are ordered, there are three avail-
able options:
• Wakeboard storage on upper and lower arms
• Wakeboard upper, and wake surf lower
Note that, regardless of the type of board or ski, it should be se-
curely clamped (or secured with a bungee cord on the ZFT0 tower)
so that board/ski does not come loose or disengage from the rack
during boat operations. DO NOT attempt to place the wrong type of
board within spokes (i.e., slalom skis in a board rack) because the fit
will be improper. Resulting loss or damage to the board, or injury to
individuals, is not the responsibility of the manufacturer.
