Powerhead
Page 4A-24 90-8M0065421 NOVEMBER 2012
NOTE: Hold the valves in place from the cylinder bore end during the disassembly procedure.
26675
8. Remove the valve keepers, valve spring retainer, spring, and spring seat.
9. Remove the intake and exhaust valves.
10. Remove the intake and exhaust valve seals.
a - Exhaust valve seal (green)
b - Intake valve seal (black)
Cleaning/Inspection/Repair
Flywheel
1. Inspect the flywheel keyway. Replace if damaged or worn.
26676
b
a
