Mercury FourStroke 3.5 User Manual

Clamp/Swivel Bracket and Driveshaft Housing
90-8M0065421 NOVEMBER 2012 Page 5A-13
4. Remove the thrust plate and split plastic bushing.
a - Thrust plate
b - Rubber bushing
c - Split plastic bushing
d - Tab
e - Front swivel bracket
Steering Co‑Pilot Components
a - Swivel bracket cap
b - Pocket for split plastic bushing tab
c - Friction pad
d - Washer and spring
e - Steering co‑pilot adjusting screw
26140
a
b
c
e
d
a
d
e
26135
a
c
b
b
