Image Optimization 5-51
 The time begins at 0.
 In live mode, there displays the elapsed time. For example,
, it means the elapsed
time is 8s.
 Freeze the image during the timing, the timer stops working, and there displays the
elapsed time. After unfreezing, the timer 1 continues working, and the timer 2 exits.
 Set [Timer 1] or [Timer 2] as “OFF”, the timer discontinues its work.
5.15.1.4 Micro-bubble Destruction
Function: destruct the micro-bubbles left by the last contrast imaging; or to observe the
reinfusion effect in a continuous agent injecting process.
 Entering: click [Destruct] on the screen to enable the micro-bubble destruction function.
 Parameters:
 DestrucAP: adjust the destruct acoustic power via the screen.
 DestructTime: adjust the destruct time via the screen.
Caution:
Use the contrast imaging according to the residual level of the micro-
bubbles, using contrast imaging continuously may result in human
harm.
5.15.1.5 Dual Live
In live mode or freeze mode, setscreen item [DualLive] as “ON” to enable dual live function.
Both the contrast mode and tissue mode are displayed. The THI and B image are displayed
on the screen if the [Dual Live] is enabled.
Tips:
 In dual live mode, the screen displays the contrast image and tissue image
 In freeze mode, there displays only one cine review progress bar as the contrast
image and tissue image are reviewed synchronously.
 Image position
The contrast appears on the left of the screen if the contrast image position is enabled.
5.15.1.6 Mix Map
This function is to mix the contrast image with the tissue image, so that interested contrast
regions can be located.
Click [Mix] to select different mixing mode, and select different maps via [Gray Map]/[Tint Map]
on the screen.
 When dual live function is on, you can see the mixed effect on the contrast image.
 When dual live function is off, you can see the mixed effect on the full screen image.
Select the map through the [Mix Map] item.
5.15.1.7 Image Saving
 Live capture
In live mode, you can save the interested images by pressing user-defined save key.
 Cine saving
In live mode, press <Freeze> on the control panel to enter cine review status.
5.15.2 Measurement, Comment and Body Mark
The system supports image measurement, comment and body mark functions. For the details,
please refer to the relevant sections.
