Mircom FA-301-12LDR User Manual

100
15.0 Appendix D: Power Supply and
Battery Calculations
Use the form below to determine the required secondary power supply (batteries).
* Assume three Initiating Circuits are in alarm.
' Use 0.084 for five minutes of alarm as a multiplier figure.
 Using the Mircom MPD-65P 2-wire photoelectric smoke detector. See Device Compatibility Guide LT1007.
Total Current Requirement:ALARM (B)______ Amp. (Value obtained from column B)
Battery Capacity Requirement:
([STANDBY (A) ______ ] X [(24 or 60 Hours) ___ ]) + ([ALARM (B) ______ ] X [Alarm in Hr.] _____) = (C) ______AH
Total Alarm Current: Must be 6 Amperes or less for FA-300 Series. Indicating Circuits must not to exceed 5 Amperes.
Battery Selection: Multiply (C) by 1.20 to derate battery.
IMPORTANT NOTICE
The main AC branch circuit connection for Fire Alarm Control Panel must provide a dedicated continuous power without provision of any
disconnect devices. Use #12 AWG wire with 600-volt insulation and proper over-current circuit protection that complies with the local codes. Refer
to Appendix A for specifications.
POWER REQUIREMENTS (ALL CURRENTS ARE IN AMPERES)
Model Number Description Qty Standby Total Standby Alarm Tota l A l a rm
FA-301-12LW
Fire Alarm
Control Panel, 12 Det,
FIXED ELR/ACTIVE ELR
X 0.164/0.104
= 0.424/0.364 =
FA-301-12LD(W/R)
Fire Alarm Control Panel, 12 Det
with UDACT
FIXED ELR/ACTIVE ELR
X 0.164/0.104
= 0.424/0.364 =
FA-301-8LW
Fire Alarm
Control Panel, 8 Det
FIXED ELR/ACTIVE ELR
X 0.136/0.096
= 0.366/0.326 =
FA-301-8LDW
Fire Alarm Control Panel, 8 Det
with UDACT
FIXED ELR/ACTIVE ELR
X 0.136/0.096
= 0.366/0.326 =
ICAC-306
Det Class A Converter Adder
Module
X 0.000
= 0.000 =
OCAC-304
Sig Class A Converter Adder
Module--4 Circuits
X 0.000
= 0.000 =
OCAC-302
Sig Class A Converter Adder
Module--2 Circuits
X 0.000
= 0.000 =
PR-300
Polarity Reversal and City Tie
Module
X 0.050
= 0.300 =
RM-312/ RM-306
12 Relay or 6 Relay Adder
Module
X 0.000
= 0.160/0.080 =
SRM-312 12 Relay Smart Relay Module X 0.030
=0.140=
RAM-300LCD Smart Remote Annunciator X 0.056
=0.065=
RAM-208/216 Remote Annunciators X 0.035
=0.090=
RTI-1 Remote Trouble Indicator X 0.035
=0.035=
Two-Wire Smoke Detectors X  0.00011
= * 0.090 = 0.090
Four-Wire Smoke Detectors X
= =
Signal Load (bells, horns, strobes, and etc.) X
=
Auxiliary Power Supply for Annunciators, etc.
=
ALARM
=
Total currents (Add above currents) STANDBY
(A) (B)
