Mircom FA-301-12LDR User Manual

79
Configuration with the CFG-300 LCD Service Tool
make sure all the devices are working properly. The following table lists the status of the
devices while in walk test.
You can cancel the maintenance test either by pressing the SYSTEM RESET button or by
going into the configuration section and canceling the test.
11.11 9. Dialer Config (Command-Menu)
Figure 52 shows the Dialer Config menu.
Figure 52 Dialer Config menu
Table 15 i3 Detector Statuses
i
3
Detector Condition
Green LED Red LED
Proper operation Double blink every 5 sec OFF
Out of sensitivity OFF Double blink every 5 sec
Freeze condition OFF Double blink every10 sec
Note: Refer to 11.2.1 Using the Keypad to Program the FA-300 on page 61 for detailed
instructions on making menu selections.
i
1 Account Info
2 Telephone line
3 Report Options
4 Time Parameter
-Dialer Config-
5 Enable/Disable
