Mircom FA-301-12LDR User Manual

15
System Components
4.6 Smart Relay Module
4.7 Input Class A converter: Six Circuits
4.8 Output Class A converter: four circuits
4.9 Output Class A converter: two circuits
Model Description
SRM-312W Smart Relay Module (12 relays) with white enclosure
SRM-312R Smart Relay Module (12 relays) with red enclosure
Model Description
ICAC-306
Input Class A converter Module (six circuits). This
module has built in Active End-of-Line resistors.
Model Description
OCAC-304 Output Class A converter module (four circuits)
Model Description
OCAC-302 Output Class A converter module (two circuits)
REMOTE RE LAY
Advanc ed Life Safety Sol utions
FR-320 SERI ES
BLK RED
BLK REDBLK REDBLK REDBLK REDBLK RED
- DET1 OUT+- DET2 OUT+- DET3 OUT+- DET4 OUT+- DET5 OUT+- DET6 OUT+
- DET1 RET+- DET2 RET+- DET3 RET+- DET4 RET+- DET5 RET+- DET6 RET+
- SIG1 OUT+- SIG2 OUT+
- SIG1 RET+- SIG2 RET+
BLK RED
BLK RED
- SIG3 OUT+- SIG4 OUT+
- SIG3 RET+- SIG4 RET+
BLK RED
BLK RED
- SIG1 OUT+- SIG2 OUT+
- SIG1 RET+- SIG2 RET+
BLK RED
BLK RED
