62
Configuration with the CFG-300 LCD Service Tool
2. Press ENTER to select an option.
The corresponding menu appears.
3. Press the up and down arrow buttons to scroll through the menu.
4. Press the left or right arrow buttons to select or unselect an option (selected = X). Use
the up and down arrows to scroll through the different options.
5. Once you have made the correct selection, press ENTER to confirm the change.
6. Press CANCEL to return to the previous menu.
11.3 1. FA-300 CONFIG (Command-Menu)
The FA-300 configuration menu is shown in Figure 39.
Figure 39 FA-300 Config menu
11.3.1 Command Menu/FA-300 Config-->Features
1. Features
2. Inp. Zone
3. I3 Zones
4. Opt. Zone
-FA-300 Config-
5. Correlation
6. Inp Zone Label
7. Opt Zone Label
8. Default Config
