Mircom FA-301-12LDR User Manual

92
Configuration with the CFG-300 LCD Service Tool
Figure 59 Four-wire Power Supply
11.21 Supervised Aux. Supply
The supervised auxiliary supply is supervised for shorts. When a short is detected on
supervised auxiliary supply the power is cut off and a trouble message is generated. Press the
SYSTEM RESET button to restore the power the system. If the short is removed, the panel
returns to normal; otherwise the trouble message remains.
Figure 60 Aux. Power Supply
11.22 City Tie Polarity reversal - PR-300/ Relay module
The city tie or polarity reversal module is supervised for open and whether or not the PR-300
is plugged in. The relay module is supervised for whether or not it is plugged in.
If any of the modules are not plugged in, the following trouble message appears:
Note: The trouble code and info is for trained service personnel only.
"INFO" Key
4Wire Pwr. Supply
short 1/ 1
Trouble Type
EVENT
01 of 01
Trb:0x03 Info:0x0001
00:07 SAT 2000-01-01
DATE
TIME
Trouble code Trouble Info
i
"INFO" Key
Aux. Power Supply
short 1/ 1
Trouble Type
EVENT
01 of 01
Trb:0x03 Info:0x0001
00:07 SAT 2000-01-01
DATE
TIME
Trouble code Trouble Info
