Mircom FA-301-12LDR User Manual

89
Configuration with the CFG-300 LCD Service Tool
11.15 Zone messages
Point annunciation is indicated on the LCD display. There are no separate queues for
TROUBLE, ALARM, SUPERVISORY and BUILDING; instead there is only one queue that
indicates all the events. The respective TROUBLE, ALARM, SUPERVISORY and BUILDING
LEDs flash if at least one of the given types is in the queue.
The CFG-300 LCD service tool shows only the first alarm or trouble. If a trouble happens first
and then an alarm happens, the alarm appears. Any further events change the total number of
events, shown in the right hand corner of the LCD display. The order of priority is alarm,
supervisory, trouble and property and building safety.
11.15.1 Example 1 (detection circuit):
Event 01 of 09, OPEN TRB on initiating circuit Z-01 in the EAST LOBBY ENTRANCE with
process type as VERIFIED ALARM and the event occurred on 2003/02/02 at 18:01
TUESDAY.
Figure 53 Detection circuit zone message
11.15.2 Example 2 (indicating circuit):
Event 02 of 09, SHORT TRB on indicating circuit NAC-01 in the EAST WING LOBBY with
process type as SILENCEABLE and the event occurred on 2003/02/02 at 18:01 TUESDAY.
Figure 54 Indicating circuit zone message
Other common messages are described below.
EAST LOBBY ENTRANCE
OPEN TRB 01/09
VERIFIED ALARM Z-01
18:01 TUE 2003-04-04
ZONE
Message
EVENT
01 of 09
Process
Type
Physical
Zone No.
DATE
TIME
"INFO" Key
EVENT
type
EAST WING LOBBY
SHORT TRB 02/09
SILENCE-ABLE NAC-1
18:01 TUE 2003-02-02
"INFO" Key
ZONE
Message
EVENT
type
EVENT
02 of 09
Process
Type
Physical
Zone No.
DATE
TIME
