FX Series Programmable Controlers Applied Instructions 5
5-17
5.2 Move And Compare - Functions 10 to 19
Contents:
Page
CMP - Compare FNC 10 5-17
ZCP - Zone Compare FNC 11 5-17
MOV - Move FNC 12 5-18
SMOV - Shift Move FNC 13 5-18
CML - Compliment FNC 14 5-19
BMOV - Block Move FNC 15 5-20
FMOV - Fill Move FNC 16 5-21
XCH - Exchange FNC 17 5-21
BCD - Binary Coded Decimal FNC 18 5-22
BIN - Binary FNC 19 5-22
Symbols list:
D - Destination device.
S - Source device.
m, n- Number of active devices, bits or an operational constant.
Additional numeric suffixes will be attached if there are more than one operand with the same
function e.g. D
1,S3 or for lists/tabled devices D3+0, S+9 etc.
MSB - Most Significant Bit, sometimes used to indicate the mathematical sign of a number, i.e.
positive = 0, and negative = 1.
LSB - Least Significant Bit.
Instruction modifications:
PPP - An instruction operating in 16 bit mode, where PPP identifies the instruction
mnemonic.
PPPP - A 16 bit mode instruction modified to use pulse (single) operation.
DPPP - An instruction modified to operate in 32 bit operation.
DPPPP - A 32 bit mode instruction modified to use pulse (single) operation.
( - A repetitive instruction which will change the destination value on every scan unless
modified by the pulse function.
) - An operand which cannot be indexed, i.e. The addition of V or Z is either invalid or will
have no effect to the value of the operand.
To Next Page
