FX Series Programmable Controller Diagnostic Devices 6
6-17
6.12 High Speed Zone Compare
Table Comparison Flags
(M8130 to M8148 and D8130 to D8148)
Diagnostic
Device
Operation
Diagnostic
Device
Operation
M8130
(Not FX1S,FX1N)
Seenote8
Selects comparison tables
to be used with the HSZ
instruction
D8130 (
7)(-)
(Not FX1S,FX1N)
Contains the number of the
current record being
processed in the HSZ
comparison table
M8131 (
7)(-)
(Not FX1S,FX1N)
Seenote8
ON when the HSZ
comparison table has been
completed.
D8131 (
7)(-)
(Not FX1S,FX1N)
Contains the number of the
current record being
processed in the HSZ
comparison table when the
PLSY operation has been
enabled
M8132
(Not FX1S,FX1N)
Seenote8
Selects the use of the PLSY
instruction with the HSZ
comparison tables
D8132
D8133
(
7)(-)
(Not FX1S,FX1N)
Contains the source (output
pulse frequency) data for the
PLSY instruction when used
with the HSZ comparison
table
M8133 (
7)(-)
(Not FX1S,FX1N)
Seenote8
ON when the HSZ
comparison table (when
used with the PLSY
instruction) has been
completed.
M8134-
M8139
Reserved
D8134
D8135
(
7)(-)
(Not FX1S,FX1N)
Contains a copy of the value
for the current comparison
when the HSZ comparison
table and combined PLSY
output are used. This data is
only available in 32 bit or
double word format.
D8136
D8137
(
7)(-)
Contains the total number of
pulses that have been output
using the PLSY (or PLSR)
instruction on Y000 and Y001.
This data is only available in
32 bit or double word format
D8138 -
D8139
Reserved
FX 1S
FX 1N FX 2NC FX 2N
Note 8
• See section 5.6.6 for full explanation and use.
