PLC Device Tables 8
8-1
8. PLC Device Tables
8.1 Performance Specification Of The FX1S
Item Specification Remarks
Operation control method Cyclic operation by stored program
I/O control method
Batch processing method (when END
instruction is executed)
I/O refresh instruction is available
Operation processing time
Basic instructions: 0.55 to 0.7 µs
Applied instructions: 1.65 to several 100 µs
Programming language Relay symbolic language + step ladder
Step ladder can be used to produce an
SFC style program
Program capacity 2K steps Provided by built in EEPROM memory
Number of instructions
Basic sequence instructions: 29
Step ladder instructions: 2
Applied instructions: 85
A Maximum 116 applied instructions
are available including all variations
I/O configuration Max total I/O set by Main Processing Unit
Auxiliary
relay
(M coils)
General 384 points M0 to M383
Latched 128 points (subset) M384 to M511
Special 256 points From the range M8000 to M8255
State relays
(S coils)
General 128 points S0 to S127
Initial 10 points (subset) S0 to S9
Timers (T)
100 msec
Range: 0 to 3,276.7 sec
63 points
T0 to T55
10 msec
Range: 0 to 327.67 sec
31 points
T32 to T62 when special M coil M8028
is driven ON
1msec
Range: 0.001 to 32.767 sec
1point
T63
Counters (C)
General
Range: 1 to 32,767 counts
16 points
C0 to C15
Type: 16 bit up counter
Latched 16 points(subset)
C16 to C31
Type: 16 bit up counter
High speed
counters (C)
1phase
Range: -2,147,483,648 to
+2,147,483,647 counts
FX0: Select upto four 1 phase counters
with a combined counting frequency of
5kHz or less.
Alternatively select one 2 phase or A/B
phase counter with a counting fre-
quency of 2kHz or less.
FX0S: When multiple 1-phase counters
are used the sum of the frequencies
must be equal or less than 14kHz. Only
1, 2 phase high speed counter may be
used at any one time. When 2 phase
counters are in use the maximum
counted speeds must be equal or less
than 14kHz, calculated as (2 ph
counter speed 5 number of counted
edges) + 1 ph counter speeds.
C235 to C240
(note C235 is latched)
6points
1phase
c/w start
stop input
C241(latched), C242 and C244
(latched) 3 points
2phase
C246, C247 and C249 (all latched) 3
points
A/B phase
C251, C252 and C254 (all latched) 3
points
FX
1S
FX
1N
FX
2N
FX
2NC
FX Series Programmable Controllers
continued over the page....
