Motorola APX 6000 Service Manual

Troubleshooting Charts: Main Troubleshooting Flowchart 5-3
5.2 Main Troubleshooting Flowchart
Start
Good
power up
self test
Any Error
Message?
See Table for
error codes
Table 4.5
No No
Yes
Go to either Display
Failure(5.19,5.20)
or Vocon power up
failure flowchart
Chart 5.3
Yes
Does the
Radio
transmit?
No
Go to TX RF
troubleshooting
Flowchart(Chart
5.45)
Is there TX
deviation?
Go to VOCON
TX Audio error
Chart(5.11)
Receive Audio
present?
Go to RX RF/
Vocon audio
flowchart(chart
5.29/5.11)
No
No
RX SINAD
GOOD?
Buttons
Functional?
No
End
See Button Test
Flowchart(chart
5.10)
Yes
Yes
Yes
Yes
No

Motorola APX 6000 Specifications

General

Frequency Range	700/800 MHz, VHF, UHF Range 1, UHF Range 2
IP Rating	IP67
P25 Phase 1 & 2	Yes
GPS	Yes
Encryption	AES, DES
Power Output	1-3 Watts (700/800 MHz)
Operating Temperature	-30°C to +60°C
Intrinsically Safe	Yes
Bluetooth	Yes (Bluetooth 4.0)
