7-2 Troubleshooting Tables: List of Board and IC Signals
Table 7-2. VOCON board to RF board connector Interface PIN-OUT
Test Place
VOCON Board RF Transceiver Board
Test
Place
signal name pin # pin # signal name
chassis GND J1001-1 P101-1 GND chassis
none EEPROM_SPI_CS J1001-2 P101-2 DIG_CTRL_SPI_EEPROM_PE TP113
C6201 16.8_MHZ_SINEWAVE J1001-3 P101-3 CLK_16_8_MHZ C754
chassis GND J1001-4 P101-4 GND chassis
chassis GND J1001-5 P101-5 GND chassis
F_VREF_1.875V V_EXT_1.85 J1001-6 P101-6 DC_LIN_1_875V_D TP124
none RF_BRD_RSTB J1001-7 P101-7 DIG_CTRL_RSTB R721
R6564 V_2.8_RF J1001-8 P101-8 DC_LIN_2_775V TP125
none DMCS J1001-9 P101-9 DIG_CTRL_SSI_TRIGGER TP114
none F2_PARAMP J1001-10 P101-10 DIG_CTRL_IO49 TP120
R1004 RX_FSYNC J1001-11 P101-11 DIG_DATA_SSI_RX_FS TP111
none TX_INH J1001-12 P101-12 DIG_CTRL_TX_INHIBIT_TYPE_1 R103
R1005 RX_DA J1001-13 P101-13 DIG_DATA_SSI_RX_DOUTA TP112
R1018 RF_DAC_SPI_CS J1001-14 P101-14 DIG_CTRL_SPI_DAC_PE TP115
R1006 RX_CLK J1001-15 P101-15 CLK_SSI_RX TP106
R6427 ISET J1001-16 P101-16 ANA_CTRL_ISET TP101
R1007 TX_FSYNC J1001-17 P101-17 DIG_TX_SSI_FS TP102
C1006 TX_DA_CONN J1001-18 P101-18 DIG_DATA_TX_SSI TP103
R1008 TX_CLK J1001-19 P101-19 DIG_TX_SSI_CLK TP104
R6505 V_COIN_CELL J1001-20 P101-20 M107 (battery) R104
L4001 GPS_ANT J1001-21 P101-21 RF_GPS TP105
none ABACUS_SPI_CS J1001-22 P101-22 DIG_CTRL_SPI_ABACUS_PE TP116
R1010 F2_SYNCB J1001-23 P101-23 DIG_SYNCB TP117
chassis GND J1001-24 P101-24 GND chassis
R1011 LOCK_DET_A J1001-25 P101-25 DIG_CTRL_LOCK TP109
none BSTAT J1001-26 P101-26 DIG_BATTERY_DATA C101
none TRIDENT_SPI_CS J1001-27 P101-27 DIG_CTRL_SPI_TRIDENT_PE TP118
F_UNSW_B+ UNSW_B+ J1001-28 P101-28 DC_FUSED_B+ C203
none SPI_DSP_MISO J1001-29 P101-29 DIG_DATA_SPI_MISO TP110
F_UNSW_B+ UNSW_B+ J1001-30 P101-30 DC_FUSED_B+ C203
