Schematics, Boards Over
lays, and Parts Lists
: Controller Board
8-129
8.8
Controller Board
Figure 8-63. HLN5979B/ HLN5960AC
ontroller Bo
ard Overall Schematic
OMAP_RESET
ACC_SPKR_UNMUTE
F_DISP_BD_ID
JTAG<11..0>
F_DISP_RW_EN
OMAP_RESET
F_DISP_DATA_CMD
F_DISP_RW
I2C_CLK
I2C_DATA
F_DISP_DATA_7
F_DISP_DATA_6
F_DISP_DATA_3
F_DISP_DATA_4
F_DISP_DATA_5
KP_ROW<4..0>
KP_COL<4..0>
F_DISP_DATA_0
F_DISP_DATA_2
ON_OFF_SWITCH
TOGGLE_1
EMERG_BTN
T_DISP_SPI_MOSI
T_DISP_SPI_CLK
T_DISP_SPI_CS
T_DISP_DATA_CMD
TOGGLE_0
SEC_CLEAR
T_DISP_RESET
VOLUME
FREQ_SEL<3..0>
F_DISP_DATA_1
F_DISP_DATA_4
F_DISP_DATA_3
F_DISP_DATA_5
F_DISP_DATA_7
I2C_CLK
F_DISP_DATA_CMD
I2C_DATA
F_DISP_DATA_6
ON_OFF_SWITCH
ARM_SPI_MOSI
ARM_SPI_CLK
F_DISP_DATA_2
F_DISP_DATA_1
T_DISP_RESET
VOLUME
FREQ_SEL<3..0>
T_DISP_DATA_CMD
T_DISP_SPI_CS
TOGGLE_1
TOGGLE_0
SEC_CLEAR
KP_COL<4..0>
KP_ROW<4..0>
JTAG<11..0>
F_DISP_DATA_0
F_DISP_RW_EN
F_DISP_BD_ID
F_DISP_RW
BT_SPARE_1.8
SUBDESIGN_SUFFIX=2
EMERG_BTN
USER_INTERFACE
DISPLAY DATA
DISPLAY/LED
TOP DISPLAY
TOP CONTROLS
CONTROL LINES
KEYPAD
JTAG
F_DISP_DATA_4
F_DISP_DATA_3
F_DISP_DATA_5
F_DISP_DATA_7
I2C_CLK
F_DISP_DATA_CMD
ACC_SPKR_UNMUTE
I2C_DATA
F_DISP_DATA_6
ON_OFF_SWITCH
SPI_ARM_MOSI
SPI_ARM_CLK
F_DISP_DATA_2
F_DISP_DATA_1
T_DISP_RESET
VOLUME
FREQ_SEL<3..0>
T_DISP_DATA_CMD
T_DISP_SPI_CS
TOGGLE_1
TOGGLE_0
SEC_CLEAR
EMERG_BTN
KP_COL<4..0>
KP_ROW<4..0>
JTAG<11..0>
F_DISP_DATA_0
F_DISP_RW_EN
F_DISP_BD_ID
F_DISP_RW
OMAP_RESET
BT_SPARE_1.8
SUBDESIGN_SUFFIX=6
USER INTERFACE
MACKINAW_CORE_CONTROLLER
EXPANSION
RF INTERFACE
INTERFACE
MACE_RESET
MAKO_USB1_POS_DP
MAKO_USB1_NEG_DP
AVR_BOOT
EXP_BOARD_TYPE
V_COIN_CELL
AVR_STATUS_1.8
MACE_WAKEUP
MACE_RESET
USB1_POS_DP
USB1_NEG_DP
AVR_BOOT
EXP_BRD_ID
V_COIN_CELL
AVR_STATUS_1.8
MACE_WAKEUP
SSI_RED_RX_CODEC
BT_AVR_RESET
ABACUS_SPI_CS
TRIDENT_SPI_CS
TRIDENT_SSI<2..0>
PRE_CLASS_D_POS_DP
HIGH_SECURE_DATA_GATE
MAKO_OPTB_SEL3_GCAI
GPIO_3_RTS_FILLSENSE
16.8_MHZ_SINEWAVE
LOCK_DET
BATT_STATUS
SECURE_HIGH_NORM
SIDE_2
SSI_RED_RX_MACE
RXDIN_5V
EXT_MIC_POS_DP
EXT_MIC_NEG_DP
SIDE_1
UART2_GPS_TX
GPS_SHUTDOWN
32KHZ_GPS_CLK
SSI_RED_TX_CODEC
UART2_GPS_RX
PA_SHTDN
ABACUS_SSI<2..0>
ISET
RF_BRD_RSTB
F2_PARAMP
PTT
EXT_SPKR_POS_DP
EXT_SPKR_NEG_DP
AUDIO_MIC_POS_DP
AUDIO_MIC_NEG_DP
RTS_FILLSEN_5V
MAKO_OPTB_SEL2_GCAI
PRE_CLASS_D_NEG_DP
SPI_DSP<2..0>
EEPROM_SPI_CS
4MHZ_MACE_CLK
SSI_OPT_FSYNC
SSI_OPT_CLK
SSI_MACE_TX_DIN
MONITOR
SSI_BLACK_TX_MACE
SSI_BLACK_RX
F2_DMCS
RF_DAC_SPI_CS
MAKO_USB2_NEG_DP
MAKO_USB2_POS_DP
MAKO_OPTB_SEL0_GCAI
ONE_WIRE_GCAI
KEYFAIL_CTRL
KVL_DETACH
MMC<5..0>
EMMC_RESET
BT_PTT
UART_GPS_TX
UART_GPS_RX
GPS_SHUTDOWN
CPLD_32KHZ_GPS_CLK
AUDIO_MIC_NEG_DP
PRE_CLASS_D_POS_DP
PRE_CLASS_D_NEG_DP
AUDIO_MIC_POS_DP
PA_SHTDN
GPS_ANT
ABACUS_SPI_CS
TRIDENT_SPI_CS
TX_SSI<2..0>
16.8_MHZ_SINEWAVE
LOCK_DET
BAT_STATUS
RX_SSI<2..0>
ISET
RF_BRD_RSTB
F2_PARAMP
SPI_DSP<2..0>
EEPROM_SPI_CS
F2_DMCS
RF_DAC_SPI_CS
V_COIN_CELL
TX_INHIBIT
GPS_ANT
EMMC_RESET
MMC<5..0>
BT_PTT
BT_AVR_RESET
MAKO_OPTB_SEL0_GCAI
ONE_WIRE_GCAI
KEYFAIL_CTRL
KVL_DETACH
MAKO_USB2_POS_DM
MAKO_USB2_NEG_DP
GPIO_3_RTS_FILLSENSE
MAKO_OPTB_SEL3_GCAI
RXDIN_5V
RTS_FILLSEN_5V
MAKO_OPTB_SEL2_GCAI
SSI_MACE_TX_DIN
SSI_RED_RX_MACE
EMERG_BTN
TX_INHIBIT
OMAP_RESET
OMAP_SSI_FSYNC
SSI_OPT_CLK
SIDE_2
MONITOR
SIDE_1
HIGH_SECURE_DATA_GATE
SECURE_HIGH_NORM
SSI_BLACK_TX_MACE
SSI_BLACK_RX
4MHZ_MACE_CLK
PTT
EXT_SPKR_POS_DP
EXT_SPRK_NEG_DP
EXT_MIC_NEG_DP
EXT_MIC_POS_DP
SSI_RED_RX_CODEC
BT_SPARE_1.8
SSI_RED_TX_CODEC
ACC_SPKR_UNMUTE
KVL_DETACH
KEYFAIL_CTRL
GPIO_0
GCAI_1_WIRE
GPIO_1_DP_TXDC_FILLREQ
SSI_MACE_TX_DIN
SSI_RED_RX_MACE
EXP_BRD_ID
AVR_STATUS_1.8
AVR_BOOT
EMERG_BTN
TX_INHIBIT
OMAP_RESET
MACE_RESET
MACE_WAKEUP
OPT_SSI_SYNC
SSI_OPT_CLK
SIDE_2
MONITOR
SIDE_1
USB1_NEG_DP
USB1_POS_DP
HIGH_SECURE_DATA_GATE
SECURE_HIGH_NORM
SSI_BLACK_TX_MACE
SSI_BLACK_RX
4MHZ__MACE_CLK
PTT
EXT_SPKR_POS_DP
EXT_SPKR_NEG_DP
GPIO_3_RTS_FILLSENSE
OPTB_SEL3_SWITCH_EN
GCAI_GPIO_2_INPUT
MAKO_OPTB_SEL2_GCAI12
EXT_MIC_POS_DP
EXT_MIC_NEG_DP
GCAI_GPIO_1_INPUT
GPIO_2_DM_RXDC_FILLDATA
EXP_BRD_ID
AVR_STATUS_1.8
AVR_BOOT
MACE_RESET
MACE_WAKEUP
USB1_NEG_DP
USB1_POS_DP
SUBDESIGN_SUFFIX=4
SIDE CONTROLS
GCAI
SSI_RED_TX_CODEC
SSI_RED_RX_CODEC
BT_AVR_RESET
MMC<5..0>
GPS_TX
GPS_RX
GPS_SHUTDOWN
GPS_BT_32KHZ
GPS_ANT
EMMC_RESET
BT_PTT
BT_SPARE_1.8
ACC_SPKR_UNMUTE
MEMORY
CARD
GPS
EXPANSION_INTERFACE
AUDIO_MIC_NEG_DP
PRE_CLASS_D_POS_DP
PRE_CLASS_D_NEG_DP
AUDIO_MIC_POS_DP
PA_SHTDN
V_COIN_CELL
GPS_ANT
F2_PARAMP
16.8_MHZ_SINEWAVE
RF_BRD_RSTB
DMCS
TX_SSI<2..0>
TRIDENT_SPI_CS
EEPROM_SPI_CS
RX_SSI<2..0>
SPI_DSP<2..0>
ABACUS_SPICS
RF_DAC_SPI_CS
ISET
LOCK_DET
TX_INH
BSTAT
SUBDESIGN_SUFFIX=1
RF_CONNECTOR
ATOD
RX
SERIAL
DAC
TX
AUDIO
