a. Right-click the small square port icon at the bottom of the graph.
This is not the larger rectangular port block under the Time (seconds) bar of the graph, but the
smaller square port icon below that.
A pop-up menu opens.
b. Make one of the following selections:
• Block.The port is blocked, that is, shut down. No traffic can go through the port.
For information about unblocking the port, see Unblock and Reenable a Port on page 38.
• Set to Highest Priority.The port is set to the highest priority.
Whether the switch functions in the Port-Based QoS mode or the 802.1P/DSCP QoS mode,
you can set the port to the highest priority. For information about reprioritizing the port to a
specific priority, see Set the Priority for a Port on page 35.
Manage Custom Performance Preset Modes
You can save your current Quality of Service (QoS) settings as a custom preset mode, including the settings
for IGMP snooping, flow control, the power saving mode, the QoS mode, rate limiting, and the priorities of
the individual ports.
The switch lets you save two custom preset modes.You can also rename or delete these custom preset
modes.
Save Your Quality of Service Settings as a Custom Preset Mode
You can save your current Quality of Service (QoS) settings as a custom preset mode that you can reapply
later.
To save your QoS settings as a custom preset mode:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SETTINGS.
The PRESET MODES page displays.The LOAD tab is automatically selected.
5. Click the SAVE tab.
The SAVE PRESET MODES page displays.
6. In the Preset Name field, enter a name from 1 to 16 characters for the custom preset mode.
7. Select the Slot 1 or 2 button.
Optimize the Switch Performance
28
Nighthawk Pro Gaming SX10 Switch Model GS810EMX
