- Click the Select All link to add all ports to the VLAN.
- Click the Remove All link to remove all selected ports from the VLAN.
- Click the icon for an unselected port to add the port to the VLAN.
- Click the icon for a selected port to remove the port from the VLAN.
The icon for a selected port displays purple.
If ports are members of the same LAG, you must assign them to the same VLAN.Note
8. Click the APPLY button.
Your settings are saved. The new VLAN shows in the PORT BASED VLAN section.
Change a Port-Based VLAN
You can change the settings for an existing port-based VLAN.
To change a port-based VLAN:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SWITCHING.
The QOS page displays.
5. From the menu on the left, select VLAN.
The VLAN page displays.
6. In the PORT BASED VLAN section, click the down arrow for the VLAN that you want to change.
7. Click the EDIT button.
8. Change the settings for the VLAN:
• VLAN Name. Enter a name from 1 to 20 characters.
• VLAN ID. Enter a number from 1 to 10.
• Ports. Select the ports that you want to include in the VLAN through a combination of the following
actions:
- Click the Select All link to add all ports to the VLAN.
- Click the Remove All link to remove all selected ports from the VLAN.
Use VLANS for Traffic Segmentation
44
Nighthawk Pro Gaming SX10 Switch Model GS810EMX
